Down Stream Injector
Start your down stream injector journey here and get your hands on the right down stream injector for your pressure washing system!
Below we have created a helpful guide so you can spec up the correct down stream injector for your pressure washer.
To use this chart and to find the correct injector start from the left hand column.
Identify the Liter per minute of your machine.
How much pressure hose do you have connected to the end of your pressure washer when you're operating it.
Then select the correct Downstream injector (DSI ) for your set up.
Liter per minute of your machine | Length of your Pressure Washing Hose in Meters (M) | Which downstream Injector to use |
15 LPM | 10m to 15m | (DSI 2) |
15 LPM | 20m - 50m | (DSI 1) |
19 LPM | 10m to 15m | (DSI 3) |
19 LPM | 20m - 50m | (DSI 2) |
21 LPM | 10m to 15m | (DSI 3) |
21 LPM | 20m - 50m | (DSI 2) |
25 LPM | 10m to 15m | (DSI 4) |
25 LPM | 20m - 50m | (DSI 3) |
Once you've added your desired downstream injector to your system.
Your going to need the correct tips for the system to work.
Once you've added the correct downstream injector to your basket.
Proceed to add a J-Rod to your so you can swap between your high a low pressure tip for when you're downstream injecting
One of the fastest ways to softwash and an industry secret!
HOW TO FIND YOUR PUMPS FLOW RATE VIDEO BELOW!
